Product Information
Our product range includes low-voltage motors, standard IEC motors (IE3, IE4, IE5), NEMA standard and high-efficiency motors, GOST ANP series motors, etc.
Standard asynchronous motors (Y, YKK, YKS, YXKK, YRKK, and YL series), variable frequency drive motors (YSPKK series), etc.
Explosion-proof motors (YB, YBX series, etc.).
Standard synchronous motors (T, TK, TM, TDMK, and TFW series), etc.
Permanent magnet motors (TYC, GCS/F series, etc.).
Replacement motors (M3BP, AMI, AXR, HXR, NXR, and NMI series), etc.
Marine motors, special-purpose motors, etc.
Power range: 0.18 kW – 20,000 kW.
Voltage range: 380V – 13.8kV.
Shaft height: 80 mm – 1120 mm.
We have obtained relevant certifications, including ISO9001, ISO14001, ISO45001, CE, ATEX, NEMA, CCS, RS, etc.
Basic Technical Parameters
Power range: 250–10,000 kW
Rated voltage: 6,000 V, 10,000 V
Rated speed: 250, 273, 300, 333, 375, 428, 500, 600 rpm
Rated frequency: 50 Hz
Protection class: IP00, IP20, IP23, IP44
Insulation class: F
Duty type: S1
Cooling method: IC01, IC37, IC81W
Mounting type: IM7311, IM5710, IM7312, IM7315
*Other parameters can be customized according to user requirements.
Ordering Information
Please provide the following details when ordering:
(1) Motor model: YK5000-2/1430
(2) Rated frequency: 50 Hz
(3) Rated power: 5,000 kW
(4) Rated voltage: 10 kV
(5) Number of poles: 2 poles
(6) Cooling method: IC01
(7) Mounting arrangement: IM7212
(8) Degree of protection: IP23
(9) Direction of rotation: Clockwise (viewed from the shaft extension end)
(10) Terminal box position: Right side of the motor (viewed from the shaft extension end)
(11) Requirements for space heaters, temperature sensing elements, etc.
![]()
![]()
Materials
Frame: Cast iron, steel
Stator: Copper
Rotor: Copper/Aluminum
Shaft: No. 45 steel
Bearings: SKF or equivalent brand
Every motor must undergo testing before leaving the factory. Motors are shipped only after passing inspection. A test report is included with each motor.
